20kHz 2000W Ultrasonic Fibar Welding Transducer Ultrasonic Mask Welding Machine Piezoelectric Welding Transducer

Item	Parameter	Advantage:	Application
28Khz ultrasonic hand welder Straight type	▪ 28Khz 800W ▪ Digital generator ▪ Horn customized ▪ Aluminum alloy&Steel & Titanium alloy ▪ Power Supply: 220v 50/60HZ	1. light generator ,light hand welder.The generator 120*120*380, whole weight5KG, with generator 4kg, and the 28Khz hand welder 1kg, 35Khz hand welder 0.8kg. Suit for hand operate. 2. Special alloy metal housing, the housing of the hand-welder is light but firm, not easy to be deformed, longer it'd using life. 3. Digital generator, it can tracking the frequency itself, easy for operate. Output /welding time adjustable, suit for both hand operate and machine operate.	PP PVC Fabric woven PE ABS PS Nylon PU PET All Thermoplastic material, the thickness 8mm in max.   Straight type suit for both hand /machine operate. Gun type suit for hand operate.
28Khz ultrasonic hand welder Gun type
35Khz ultrasonic hand welder Straight type	▪ 35Khz 500W ▪ Digital generator ▪ Horn customized ▪ Aluminum alloy&Steel & Titanium alloy ▪ Power Supply: 220v 50/60HZ		PP PVC Fabric woven PE ABS PS Nylon PU PET All Thermoplastic material, the thickness 5mm in max.   Straight type suit for both hand /machine operate. Gun type suit for hand operate.
35Khz ultrasonic hand welder Gun type
For better application , it is better share all the material information with me, the material, thickness, operate way, speed requirements before order . We also supply 20Khz 40Khz ultrasonic hand-weld welder.

Ultrasonic spot welding machine can be used for thermoplastics welding by converting 50/60 Hz current to 15, 20, 30, or 40 kHz power through the ultrasonic generator. The converted high-frequency electrical energy is again converted into mechanical motion of the same frequency through the ultrasonic transducer, and the mechanical motion is then transmitted to the welding head through a set of amplitude modulator devices(booster) that can change the amplitude. The vibration energy received by the welding head is transferred to the joint of the workpiece to be welded. In this area, the vibration energy is converted into heat energy by means of friction to melt the plastic. After the vibration stops, the transient pressure maintained on the workpiece causes the two weldments to solidified into one body in the form of molecular linkage. Generally, the welding time is less than 1 second, and the welding strength obtained can be comparable to the body.


Features:

* Good quality famous brand components are used to realize the strong power and stable performance.
* Compact design with small size, saving space.
* Low noise, low power consumption, environment friendly
* High efficiency with strong welding results.

Application:

Use Attention:

1. The welding horn must be tightened while in replacement
2. Do not use the machine if the current is too high
3. Make sure the equipment is connected with the grounding line for the security purpose
4. Two wrenches must be used while installing or dismantling the horn to prevent damaging the converter
5. Do not modify the welding horn without permission or the consequences will be at your side
6. Non-professionals shall not dismantle the machine for maintenance
